ABB Mini Contactor 9A

The ABB Mini Contactor 9A is a compact, three-pole contactor designed primarily for controlling single-phase and three-phase motors and power circuits up to 690 V AC or 220 V DC, with a rated operational current of 9 ampere (AC-3).

Key Features

• Compact Design: Space-saving, ideal for applications where space is at a premium such as control panels in residential, commercial, and industrial settings.

• Contact Configuration: 3 main contacts (poles) and 1 built-in auxiliary contact (normally open), suitable for various control needs.

• Rated Current and Power: 9A (AC-3), capable of controlling loads up to 4 kW, with a maximum contact voltage rating of 690 V AC.

• Reliable Operation: High switching frequency allows up to 1200 cycles per hour (AC-3), suitable for frequent operation
