Type: Vertical TPN (Triple Pole & Neutral) Distribution Board
-
Number of Ways: Available in variants such as 4, 6, 8, 12, 16 ways
-
Enclosure: Powder-coated CRCA sheet steel with RAL9003 white finish
-
Protection Rating: IP43 for dust and water resistance
-
Door: Metal double door option for secure and convenient access
-
Mounting: Surface or flush mounting with removable chassis & door for easy installation and maintenance
-
Bus Bar: Insulated vertical phase bus bars, neutral bars with shrouds for enhanced safety
-
Incoming: Provision for 3-pole and 4-pole MCCB as incomer and SP/TP MCBs as outgoing feeders
-
Standards Compliance: IS 8623-1 & 3, IEC 61439-1 & 3
-
Impact Protection: IK08 for single door, IK09 for double door DBs
-
Additional features: Cement spill protector, color-coded wire set with cable ties, blanking plates, circuit identification labels
-
Operating Temperature: -5°C to 50°C
