Conductor: Plain annealed copper, finely stranded for flexibility with about 16 strands of 0.2 mm diameter each.
-
Insulation: FR-LSH (Flame Retardant Low Smoke & Halogen) PVC insulation that restricts fire spread and toxic gas emission for enhanced safety.
-
Voltage Grade: Suitable up to 1100 V.
-
Overall Diameter: Approximately 2.1 mm.
-
Current Carrying Capacity: Rated for about 5 amps, ideal for small load circuits.
-
Conductor Resistance: Around 39 ohms per kilometer at 20°C.
-
Usage: Suitable for internal electrification, lighting circuits, control wiring, and general purpose flexible wiring inside buildings.
