The Polycab 95 sqmm 3 core 6.6 KV (UE) - 11 KV (E) H.T XLPE Armoured Aluminium Cable is a high-tension medium voltage power cable suitable for industrial and infrastructure power transmission applications. Its key specifications are:
-
Conductor: Stranded aluminium, 95 sqmm cross-sectional area
-
Number of cores: 3
-
Insulation: XLPE (Cross-linked polyethylene) offering excellent thermal, mechanical, and electrical properties
-
Armour: Flat strip armoured for mechanical protection and durability
-
Voltage rating: Dual rated at 6.6 KV (UE) and 11 KV (E)
-
Outer sheath: Flame retardant, low smoke (FRLS) and PVC options depending on application
-
Compliance: Manufactured as per IS 7098 (Part 2) and IEC 60502-2 standards
-
Temperature tolerance: Rated for normal operation at 90°C, emergency operation up to 105°C, and can withstand short-circuit temperatures up to 250°C
-
Applications: Designed for heavy duty power transmission in three-phase industrial, commercial, and urban electric networks
