Polycab Unarmoured Screened 0.5 sqmm 16/.20 Multi-core Cable is a specialized flexible cable designed for control, instrumentation, communication, and industrial signal transmission purposes.
-
Conductor: Annealed copper, multi-stranded, 16 strands of 0.20 mm diameter per core (standard for 0.5 sqmm IS 694 cables)
-
Cross-sectional Area: 0.5 sqmm per core
-
Voltage Rating: 1100 V
-
Screening: Typically consists of copper wire braid or aluminium foil (confirm specific catalog for screen construction)
-
Insulation: PVC Type A or D, per IS 5831
-
Outer Sheath: Overall PVC round sheath (unarmoured type)
-
Typical Configuration: 2 to 24 cores available, including 16-core variants
-
Standard: IS 694:2010, IS 8130:2013
-
Typical Colors: Conductors color-coded as per IS norms, sheath usually black or grey
