Schneider 4 Pole 9A Contactors

The Schneider 4 Pole 9A Contactors, such as the LC1D098F7 model, are reliable electrical devices designed for switching and controlling circuits. These contactors have the following key features:

• Rated current: 9 Amps

• Number of poles: 4 (typically configured as 2 normally open (NO) and 2 normally closed (NC) power poles)

• Auxiliary contacts: Usually 1 NO and 1 NC base-mounted auxiliary contacts

• Coil voltage options include 110V AC, 220V AC, or 48V DC depending on specific model

• Rated insulation voltage: 600V (UL/CSA certified)

• Rated impulse withstand voltage: 6 kV

• Conforming standards: IEC 60947-1, IEC 60947-4-1, VDE 0660, EN 60947-1, EN 60947-4-1

• Degree of protection: IP 2X

• Mechanical durability: Around 15 million operating cycles

• Compact design for DIN rail or screw mounting
