The Schneider Time Delay Relay, model RE22R2QEMT, is designed for industrial automation applications with a coil voltage of 415V AC. It features a star-delta delay function with two delay settings, adjustable from a minimum of 0.3 seconds to a maximum of 30 seconds. The relay has a DPDT (Double Pole Double Throw) contact form, rated for 8 Amps at 250V AC or 8 Amps at 24V DC.
This relay is DIN rail mountable and connects via screw terminals. It has six pins and a square base shape. Its input voltage range is between 380 and 415V AC, with an electrical operating frequency of 50/60 Hz. The relay includes a diagnostic button and rotary dip switch for time adjustment, and an LED status indicator. Its mechanical and electrical durability are rated at 10 million and 100,000 operations respectively.
